Description
The Markaudio Pluvia 7 P Mica is a compact full‑range driver designed for builders who want a natural, unforced presentation with excellent dispersion and a clean, modern tonal balance. At the centre of the design is a paper cone reinforced with mica, a combination that increases stiffness without adding weight. The result is a driver that stays composed at higher levels, with improved transient definition and reduced cone‑breakup artefacts.
Markaudio have tuned the 7 P Mica to deliver a smooth, even midband and a lightly extended top end, giving it a more neutral and open character than earlier paper‑cone models. Vocals sit forward without becoming shouty, and the treble has enough sparkle to give acoustic instruments and percussion a sense of air, while still avoiding the sharpness that can creep into metal‑cone designs.
The shallow cone profile and carefully shaped surround help the driver maintain very wide dispersion, making it easy to integrate in small rooms, desktop systems, or compact floorstanders. Behind the cone, a low‑distortion motor, long‑stroke suspension, and progressive spider keep the driver under control at higher excursions, while the vented polymer frame reduces compression and improves airflow around the motor.
With an Fs of 72 Hz, VAS of 4.5 L, and sensitivity of 90.6 dB, the Pluvia 7 P Mica works well in small vented or sealed enclosures and is particularly well suited to full‑range designs where coherence and imaging matter more than sheer output. Its tonal balance also makes it a strong match for solid‑state, Class‑D, and hybrid amplifiers.
For builders looking for a driver that combines natural timbre, broad dispersion, and a refined top end, the Pluvia 7 P Mica offers a compelling blend of musicality and technical performance.
Markaudio Pluvia 7 P Mica Key Features
- Mica‑reinforced paper cone for improved stiffness and cleaner transients
- 70 mm wide‑range design with smooth, natural voicing
- Very wide dispersion from a shallow cone profile
- Low‑distortion motor with long‑stroke suspension
- Progressive‑rate spider for controlled excursion
- Open polymer basket for reduced compression and better airflow
- Balanced midrange and extended treble without harshness
- Ideal for compact full‑range loudspeaker designs
Markaudio Pluvia 7 P Mica Core Specifications
- Impedance: 4 Ω
- Fs: 72 Hz
- VAS: 4.5 L
- Sensitivity: 90.644 dB
- Cone: Paper with mica reinforcement
- Magnet: Double ferrite
- Basket: Reinforced polymer
Markaudio Pluvia 7 P Mica Data Sheet
You can find the data sheet which also includes a couple of plans for cabinets – here
Markaudio Pluvia 7 P Mica Plans
As usual there are loads of plans produced by Scott Lindgren for this driver – more can be found on Markaudio’s own website
Pluvia 7P Mica Semi Array with MA200 P Band Pass
Pangolin MkII compact Pluvia 7 P Mica Mass Loaded Transmission Line
Pluvia7 P Mica Sealed Standmount
Pluvia 7 P Mica Traditional Compact Vented Standmount
Pluvia 7 P Mica Vented Box Standmount
Pluvia 7 P Mica Series Multichamber MLTL
Pluvia 7 P Mica Series Pair Vented Box Standmount
And of course these will work with the SL7-SD speaker kits that we sell over here and work well in the Frugel-Horn Mk3 which you can see here
